RADIO RIG ICOM IC-2300H VHF 65 W HM133 NEW ORI BERGARANSI
Kondisi Barang : Baru
Harga : Rp 2.050.000
Location : Jawa Barat
Jual RADIO RIG ICOM IC-2300 H VHF 65 W MIC HM133 NEW ORI Special Price: IDR 2.050.000 belum termasuk Ongkir.Bisa COD sekitar Jakarta Utara, Bekasi, Jati Asih.Ready stok dalam jumlah banyak per tgl 26/1/2016
Icom IC-2300H adalah model terbaru radio rig dari Icom dengan putput 65W body terbuat dari bahan aluminium menyediakan pembuangan panas lebih efektif. Pembelian bisa melalui toko Pedia nama toko Solusi Radio.
Facebook :Solusi Radio
General Specification ICOM IC-2300H
Frequency coverage TX: 144–148MHz,
RX: 136–174MHz*
Number of channels 207 channels
(including 6 scan edges, and 1 call)
Type of emission F2D, F3E (FM)
Power supply requirement 13.8V DC ±15%
Current drain Tx (65W) 11A
Rx Stand-by 0.4A
Max. audio 1.5A
Antenna impedance 50Ω (SO-239)
Operating temperature range –10°C to +60°C; 14°F to +140°F
Dimensions
(projections not included; W×H×D) 140×40×162 mm;
5.51×1.57×6.38 in
Weight (approx.) 1.1 kg; 2.43lb
* Guaranteed range TX/RX: 144–148MHz
Transmitter
Output power* (at 13.8V DC) 65W, 25W, 10W, 5W
Max. frequency deviation Wide ±5.0kHz
Narrow ±2.5kHz
Spurious emissions Less than –60dBc
Frequency stability ±3ppm
Microphone impedance 600Ω (8-pin modular)
* Output power differs depending on version and specific regulatory requirements.
Receiver
Intermediate frequencies 46.35MHz/450kHz
Sensitivity at 12dB SINAD Less than 0.18μV
Adjacent channel
selectivity Wide More than 6kHz (at 6dB)
Less than 14kHz (at 60dB)
Narrow More than 3kHz (at 6dB)
Less than 9kHz (at 55dB)
Spurious response rejection More than 60dB
Audio output power 4.5W typ. (10% dist. 4Ω load)
External speaker connector 2-conductor 3.5 (d) mm (1⁄8ʺ)/4Ω
Applicable U.S. Military Specifications
Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.
Standard MIL 810G
Method Procedure
Low Pressure 500.5 I, II
High Temperature 501.5 I, II
Low Temperature 502.5 I, II
Temperature Shock 503.5 I-C
Solar Radiation 505.5 I
Vibration 514.6 I
Shock 516.6 I, IV
